BMW X1: ENGINES & TECHNICAL DATA.

The key facts and figures for the BMW X1 at a glance:


  • Engine, consumption and CO2 emissions
  • Performance data such as displacement, kW, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
THE X1 BMW X1: ENGINES & TECHNICAL DATA.

The key facts and figures for the BMW X1 at a glance:


  • Engine, consumption and CO2 emissions
  • Performance data such as displacement, kW, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
Read more
BMW X1: Overview
Build & Price

TECHNICAL DATA.

System Power

Powertrain type Electric
Power in Kw 150 (204)
Torque in Nm 250
Gearbox 1-speed, automatic
Drivetrain Front-wheel drive

BMW eDrive

Continous power in kW (hp) 68 (92)
Nominal torque in Nm 250

Performance

Maximum speed in km/h 170
Acceleration 0–100 km/h in s 8.6

Measurements

Length/Width/Height 4,500 / 1,845 / 1,616
Wheelbase in mm 2,692 / 11.7
Ground clearance in mm 170

Weight

Curb weight in kg 1,940
Maximum weight in kg 2,435
Permitted load in kg 570
Permitted Axel load front/rear in kg 1,225 / 1,280
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 490 - 1495

Wheels

Tire front 205/65 R17 100 Y XL
Tire rear 205/65 R17 100 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

System Power

Powertrain type Electric
Power in Kw 230 (313)
Torque in Nm 494
Gearbox 1-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

Continous power in kW (hp) 94 (128)
Nominal torque in Nm 494

Performance

Maximum speed in km/h 180
Acceleration 0–100 km/h in s 5.6

Measurements

Length/Width/Height 4,500 / 1,845 / 1,616
Wheelbase in mm 2,692 / 11.9
Ground clearance in mm 170

Weight

Curb weight in kg 2,085
Maximum weight in kg 2,580
Permitted load in kg 570
Permitted Axel load front/rear in kg 1,225 / 1,415
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 490 - 1495

Wheels

Tire front 205/65 R17 100 Y XL
Tire rear 205/65 R17 100 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

System Power

Powertrain type Electric
Gearbox 1-speed, automatic

Range Charging

Battery capacity in kWh 64.8

System Power

Powertrain type Petrol
Power in Kw 115 (156)
Torque in Nm 230
Gearbox 7-speed, automatic
Drivetrain Front-wheel drive

Motor

Cylinder/ Valves per cylinder 3 / 4
Displacement in cm³ 1,499
Internal combustion engine power in kW 115 (156) / 4900 - 6500
Max torque(Nm) per 1/min 230 / 1500 - 4600

Performance

Maximum speed in km/h 215
Acceleration 0–100 km/h in s 9

Measurements

Length/Width/Height 4,500 / 1,845 / 1,642
Wheelbase in mm 2,692 / 11.7
Ground clearance in mm 205

Weight

Curb weight in kg 1,575
Maximum weight in kg 2,075
Permitted load in kg 575
Permitted Axel load front/rear in kg 1,090 / 1,050
Allowed unbraked trailer load / drawbar load in kg 750 / 80
Luggage capacity in l 540 - 1600

Wheels

Tire front 205/65 R17 100 Y XL
Tire rear 205/65 R17 100 Y XL
Rim front 7Jx17 LM
Rim rear 7Jx17 LM

Consumption

Fuel capacity in l 54

System Power

Powertrain type Petrol
Power in Kw 150 (204)
Torque in Nm 300
Gearbox 7-speed, automatic
Drivetrain All-wheel drive

Motor

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Internal combustion engine power in kW 150 (204) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1450 - 4500

Performance

Maximum speed in km/h 233
Acceleration 0–100 km/h in s 7.4

Measurements

Length/Width/Height 4,500 / 1,845 / 1,642
Wheelbase in mm 2,692 / 11.7
Ground clearance in mm 205

Weight

Curb weight in kg 1,670
Maximum weight in kg 2,160
Permitted load in kg 565
Permitted Axel load front/rear in kg 1,135 / 1,095
Allowed unbraked trailer load / drawbar load in kg 750 / 80
Luggage capacity in l 540 - 1600

Wheels

Tire front 205/65 R17 100 Y XL
Tire rear 205/65 R17 100 Y XL
Rim front 7Jx17 LM
Rim rear 7Jx17 LM

Consumption

Consumption overall in l/100km 7.2
Co2 overall in g/km 164
Fuel capacity in l 54

System Power

Powertrain type Petrol
Power in Kw 233 (317)
Torque in Nm 400
Gearbox 7-speed, automatic
Drivetrain All-wheel drive

Motor

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Internal combustion engine power in kW 233 (317) / 5750 - 6500
Max torque(Nm) per 1/min 400 / 2000 - 4500

Performance

Maximum speed in km/h 250
Acceleration 0–100 km/h in s 5.4

Measurements

Length/Width/Height 4,505 / 1,845 / 1,622
Wheelbase in mm 2,692 / 11.7
Ground clearance in mm 189

Weight

Curb weight in kg 1,740
Maximum weight in kg 2,240
Permitted load in kg 575
Permitted Axel load front/rear in kg 1,145 / 1,190
Luggage capacity in l 540 - 1600

Wheels

Tire front 245/45 R19 102 Y XL
Tire rear 245/45 R19 102 Y XL
Rim front 8Jx19 LM
Rim rear 8Jx19 LM

Consumption

Consumption overall in l/100km 8.5
Co2 overall in g/km 192
Fuel capacity in l 54
